Check the listing for details. KAKA INDUSTRIAL HV Horizontal Vertical Rotary Table, Precision Milling Table. Condition: New. Listed at 235.99 USD. SKU 162311 Model HVP-41 Table dia. 110 mm/4.3" Morse taper of the center hole MT2 Height of center for vertical mounting 59 mm/2.3" Width of T slot 8 mm/0.31" Adjacent angle of T-slot 90° Width of the locating key 12 mm/0.47" Modules of worm and worm gear 1 Transmission ratio of the worm gear 1:72 Graduation of the table 360 ° Rotating angle of the table with one revolution of worm 5 Index Plate A 15, 16, 17, 18, 19, 20 Index Plate B 21, 23, 27, 29, 31, 33 Index Plate C 37, 39, 41, 43, 47, 49 Packing size 29x24x13 cm/11.4x9.4x5.1 inch N.W./G.W. 10/11 kg 21/24lbs SKU 161110 161112 Model HV-10 HV-12 Table dia. 250mm/10" 300 mm/11.8" Morse taper of the center hole MT3 MT4 Height of center 165 mm/6.5 195 mm/7.6" Width of T slot 12 mm/0.5 14 mm/0.55 Adjacent angle of T slot 60° 60° Width of the locating key 16 mm/0.6 16 mm/0.62" Modules of worm and worm gear 2 2.5 Transmission ratio of the worm gear 1:90 1:90 Graduation of the table 360 ° 360 ° Rotating angle of the table with one revolution of the worm 4” （1‘ per graduation) 4” （1‘ per graduation) Min. value of vernier 10" 10" Indexing accuracy 60" 60" Max. loading (Table horizontal) 200 kg/441lb 250 kg/551lbs Max. loading (Table vertical) 100 kg/220lb 125 kg/275lbs Packing size 43x35x18 cm/17x14x7 inch 51x43x21 cm /20x17x8.2 inch N.W./G.W. 43/45 kg 95/100lbs 71/73 kg 156/161lbs Item No. 161104 161106 161108 Model HV-4 HV-6 HV-8 Diameter of table φ3" φ5.9" φ7.8" Morse taper of the center hole MT2 MT3 MT3 Height of center for verti mounting 2.32" 3.9" 5.3" Width of T-slot 0.314" 0.472" 0.472" Adjacent angle of T-slot 90" 90" 90" Width of the locting key 0.472" 0.62" 0.62" Modules of worm and worm gear 1 1.5 1.5 Transmission ratio of the worm gear 1:36 1:90 1:90 Graduation of the table 360° 360° 360° Rotating angle of table with one revolution of the wrom / 4"(1' Per graduation) 4"(1' Per graduation) Minimum value of vernier / 10" 10" Indexing accuracy / 80" 80" Max.bearing(With table Hor.) 220lbs 220lbs 330lbs Max.bearing(With table ver.) 100lbs 110lbs 165bs N.W./G.W. 17/19Ibs 30/33Ibs 62/67Ibs Case dimensions 7.3x3.7x4.4in 10x9.4x5.1in 15x12x7in
