Check the listing for details. (1 PC) XP1026-BD-000V MACOM RF Amplifier IC General Purpose 27GHz ~ 32GHz. Condition: New. Listed at 249.95 USD. THIS IS FOR (1 PC) OF XP1026-BD-000V BY MACOMRF Amplifier IC General Purpose 27GHz ~ 32GHz Mfr MACOM Technology Solutions Series - Package Bulk Part Status Active Frequency 27GHz ~ 32GHz P1dB 32dBm Gain 21dB Noise Figure - RF Type General Purpose Voltage - Supply 5.5V Current - Supply 550mA Test Frequency - Package / Case Module Supplier Device Package - Base Product Number XP1026 XP1026-BD-000V Product Details MACOM’s three stage 27.0 to 32.0 GHz GaAs MMIC power amplifier has a small signal gain of 21.0 dB with +33 dBm saturated output power. It can alos be used in low power linear applications, with and OIP3 of 40dBm. This MMIC uses MACOM’s GaAs PHEMT device model technology, and is based upon electron beam lithography to ensure high repeatability and uniformity. The chip has surface passivation to protect and provide a rugged part with backside via holes and gold metallization to allow either a conductive epoxy or eutectic solder die attach process. This device is well suited for Millimeter-wave Point-to-Point Radio, LMDS, SATCOM and VSAT applications. Feature Ka-Band 2W Power Amplifier 100% Visual Inspection to MIL-STD-883 Method 2010 100% On-Wafer RF, DC and Output Power Testing +40.0 dBm Output Third Order Intercept (OIP3) +33.0 dBm Saturated Output Power 21.0 dB Small Signal Gain RoHS* Compliant 260°C Reflow Compatible Applications Aerospace and Defense SATCOM VSAT Wireless Networking and Communication Applications Min Frequency: 27,000 MHz Max Frequency: 32,000 MHz Gain: 21 dB OIP3: 40 dBm Output P1dB: 32 dBm Bias Voltage: 5 V Bias Current: 900 mA Listing and template services provided by inkFrog
