Check the listing for details. 10ft Mogami W2524 Miniature #20AWG Diameter Cable for Guitar Effects Pedalboards. Condition: New. Listed at 19.00 USD. 10ft Mogami W2524 Miniature #20AWG Diameter Cable for Guitar Effects Pedalboards At Music Store Live we're all musicians like you, and we know how hard it can be to afford all the gear that you want and need. We encourage you to make us an offer. Often times, you'll be pleasantly surprised! Additionally, don't hesitate to contact us regarding financing options. We'll do everything we can to help get that next piece of gear into your hands. Manufacturer's Description Most musical instrument sound pick-ups, for example those in electric guitars, are comprised of high impedance circuits driven mainly by voltage, with very little electrical current flow. That is why handling noise (microphonics) can be a problem for guitar cables. Microphonic noise is caused by the minute voltage generated when a cable is flexed, stepped on, etc. Guitar cables must be designed to prevent this, so a conductive PVC layer is placed under the shield conductor to drain away this voltage. Note: This conductive layer must be stripped back when wiring, or a partial short will result. Specifications Conductor Details: 50/0.12A Size(mm²): 0.565mm² (#20AWG) Insulation Ov. Dia.(mm): 2.7Ø (0.106") Material: PE Color: Clear Sub-Shield Ov. Dia.(mm): 3.3Ø (0.130") Material: Conductive PVC (Carbon PVC) Color: Black Main-Shield Served-Shield: Approx. 55/0.18A Jacket Ov. Dia.(mm): 6.0Ø (0.236") Material: PVC Color: Black Roll Sizes: 100m (328Ft) / 200m (656Ft) Weight per 100m (328Ft) roll: 5.1Kg ELECTRICAL & MECHANICAL CHARACTERISTICS DC Resistance at 20°C Inner Conductor: 0.033Ω/m(0.010Ω/Ft) Shield Conductor: 0.014Ω/m(0.0043Ω/Ft) Capacitance at 1kHz, 20°C: 130pF/m (39.7pF/Ft) Inductance: 0.2µH/m (0.061µH/Ft) Electrostatic Noize*: 0.15mV Max. Electromagnetic Noise At 10kHz*: 0.07mV Max. Microphonics*: 0.3mV Max Voltage Breakdown: Must withstand at DC 500V/15sec. Insulation Resistance: 100000 MΩ × m Min. at DC 500V , 20°C Flex Life: 15,000 cyles Tensile Strength (26°C, 65%RH): 578 N Emigration: Non-emigrant to ABS resin Applicable Temperature: -20°C‾ +60°C(-4°F‾ +140°F)
