| All returns accepted | ReturnsNotAccepted |
|---|---|
| Compatible Brand | PRV Audio |
| Throat Diameter | 2” (50.8 mm) |
| Size | 2" |
| Nominal Coverage | Horizontal 30° / Vertical 30° |
| Baffle Cutout | Diameter 7.9″ (200.7 mm) |
| Compatible Model | 2" Compression Drivers |
| MPN | WGP22-50X WHITE |
| Material | Plastic (ABS) |
| Mounting Type | Bolt-on |
| Depth | 10.85″ (275.5 mm) |
| Brand | PRV Audio |
| Type | Horn/Flare without Driver |
| Unit Type | Unit |
| Flare type | Hybrid |
| Bolt Circle | 4″ 102 mm |
| Mount Depth | 10.32″ (262 mm) |
| Height | 9.00″ (228.6mm) |
| Hole Dimensions | 0.31″ 8 mm |
| Net weight | 1.23lb (0.56 kg) |
| Finish / Coating | Black/White |
| Unit Quantity | 1 |
| Width | 9.00″ (228.6 mm) |
Check the listing for details. 1x PRV Audio WGP22-50X WHITE 2" Exit Waveguide 2 inch Driver 4 Bolt Horn. Width: 9.00″ (228.6 mm), Condition: New. Listed at 39.91 USD. INCLUDES: 1x PRV WGP22-50X WHITE 2" Exit Long Throw Horns FEATURES: We are proud to present the WGP22-50X Series. We have implemented our cutting-edge technology from the WGP14-50X Horn Series, which features an unique octagonal shape engineered not only for outstanding looks, but to dramatically increase dispersion and output on vocal frequency range!Designed to reproduce the highest vocal output possible, this long throw horn can take your custom system to the next level. The WGP22-50X Horn Series is a waveguide with a 2″ throat exit designed to work with any of our 2" Exit Midrange Compression Drivers.This new series is available in BLACK or WHITE finishes, making it easy to blend with any color system.Long throw design allows mounting to 2″ midrange drivers and amplifying vocal responseSquared outside edges allow easy side or up stacking of multiple drivers in a compact format2″ throat with standard 4-bolt mounting patternNon-resonant reinforced plastic constructionThe 30° x 30° dispersion is suitable for direct focus output with a low 350Hz cutoff frequency GENERAL SPECIFICATIONSThroat Diameter2” (50.8 mm)Mounting TypeBolt-on Hole Dimensions0.31″ 8 mm Bolt Circle4″ 102 mmNominal Coverage Horizontal30° Vertical30°Flare typeHybridMaterialPlastic (ABS)Finish / CoatingBlack/WhiteDimensions Height9.00″ (228.6mm) Width9.00″ (228.6 mm) Depth10.85″ (275.5 mm) Mount Depth10.32″ (262 mm)Baffle Cutout Diameter7.9″ (200.7 mm)Net weight1.23lb (0.56 kg)
