2 Strings Solar Combiner Box FIT Solar Panel Disconnect Switch Circuit Breaker

Name: 2 Strings Solar Combiner Box FIT Solar Panel Disconnect Switch Circuit Breaker
SKU: 318088188674
Price: 80.28 USD
Availability: InStock

$40.14

$80.28 -50%

Brand Unbranded

Condition New

Item ID 318088188674

Brand	Unbranded
Material	PC, ABS
Color	White, Black, Clear
Mount Type	Wall-mounted
Protection Rating	IP65
Impact Resistance Rating	IK10
Working Temperature	-25~55°C/-13~131°F
Maximum DC Short-circuit Current Per Input	40A
Maximum Current Output / Rated Current (Ue)	40A
DC Circuit Breaker Model	63DC 2P 40A 1000V
DC Surge Arrester Model	SP-D2 2P 20-40KA 1000Vdc T2
Rated Insulation Voltage (Ui)	1000V
Circuit Breaker	63DC 2P 40A 1000V
DC Surge Arrester	SP-D2 2P 20-40KA 1000Vdc T2
Applicable Cable	4-16mm²/10-5AWG Cable
Surge Protection	20-40kA 2P DC1000V
Inputs	2 Strings
Outputs	2 Strings
Total Height	28.5cm/11.22 in
Product Size	211021cm/8.263.938.26 in
Package Size	25.82212cm/10.168.664.72 in
Gross Weight	3kg/6.61 lbs
Net Weight	2.8kg/6.17 lbs

Check the listing for details. 2 Strings Solar Combiner Box FIT Solar Panel Disconnect Switch Circuit Breaker. Color: White, Black, Clear, Condition: New. Listed at 80.28 USD. Package Included 1* Solar Combiner Box 8* MC4 Terminals 1* Ground Wire All Accessories for Use Notes 1.Please check the specifications before purchasing. 2.Please press the button correctly to avoid damage to the circuit breaker and use it at the proper operating temperature to avoid overheating and stopping operation. 3.Please allow the slight color difference caused by the shooting light and 1-3cm error due to manual measurement and make sure you do not mind before ordering.
