Check the listing for details. 2pcs Prototyping adapter/DIP breakout PCB board, TSSOP-24/SSOP-24, P=0.65/0.635. Condition: New. Listed at 0.99 USD. Use this prototyping adapter (breakout board) to experiment with surface-mount chips on a breadboard, or use it to prototype your designs on solderable perfboard. This board is designed to work with solderless breadboards as well as blank prototyping PCBs with 0.1″ hole patterns. Specifications Board size: 15.2 mm × 30.44 mm (0.6″ × 1.2″), 1.6 mm thick Surface finish: HASL with solder containing lead (Pb) IC footprint (front side): TSSOP-24 and SSOP-24, 24-pin, pad pitch 0.65 mm IC footprint (rear side): SSOP-24, 24-pin, pad pitch 0.635 mm Passive footprints (each side): 4× 0402/0603/0805/1206 capacitor/resistor, one for each corner pin (1, 12, 13, and 24) between pin and shared ground plane Pin header footprint: 2× 12-position male pin headers, 2.54 mm (0.1″) pin pitch, 12.7 mm (0.5″) row pitch Optional pin headers: As above, with 0.8μ″ gold plating for easy solderability Footprints for Passive Components This board contains footprints for passive components between each corner pin (1, 12, 13, and 24) and a shared ground plane, so that you can add bypass capacitors directly on the board. This feature works for any IC which places its power pins (VCC and GND) in the corners, which is typical. The passive footprints are designed to work with sizes 0402, 0603, 0805, and 1206. This feature is optional, but can be a boon for supply bypass close to the IC. To use this feature: Solder 0 Ω resistors (jumpers) to the footprints which are next to each pin which your IC uses for GND. This connects the adapter ground plane to IC GND. Solder capacitors to the footprints next to one or more supply pins in order to add local bypass capacitance for that pin. Included With This Listing 2× breakout boards If the "Pin Headers: Included" option is chosen: 4× 12-position male pin headers Breakout boards and pin headers (if selected) may be joined together into break-away strips. Pin header strips will always be supplied in multiples of 12 positions. Shipping & Tracking No matter where you are located or which shipping service you select, you may buy multiple lots of breakout boards, and also mix and match different types of breakout boards, all at no extra shipping cost. To take advantage of combined shipping, add your breakout boards to your cart, then complete the checkout process. There are some cases where the combined shipping is not accurately calculated. If your shipping cost seems to be too high, then please click the "request a total" option before paying, and I will manually lower the shipping cost for your order. If that option is not available to you, then please add a note to your order so that I can manually issue a partial refund of any overpayment for your shipping costs. Buyers in the United States, the Marshall Islands, Micronesia, and Palau This also applies to buyers in American Samoa, Guam, Northern Mariana Islands, Puerto Rico, U.S. Virgin Islands, and Wake Atoll. Economy Shipping ($2.01) Sent with USPS First-Class Mail. This is the default, does not include tracking, and may take 2–10 business days for delivery. It's not supposed to be any slower than Ground Advantage, but in practice, mailpieces without tracking barcodes may not get as much attention from postal workers. Standard Shipping ($4.82–$5.42) Sent with USPS Ground Advantage (similar to the old First-Class Package service). Includes tracking and delivery in 3–6 business days. Expedited Shipping ($9.60) Sent with USPS Priority Mail. Includes tracking and delivery in 2–4 business days. Buyers in Canada Economy Shipping (11.91 USD) Sent with Pirate Ship Simple Export Rate. Includes tracking and delivery in about 1–3 weeks via Canada Post. Standard Shipping (30.53 USD or less) Sent with UPS Standard. Includes tracking and delivery in about 1 week. For most Canadian destinations, shipping will be less expensive than this. Add items to your cart and click "request a total" to get the most accurate shipping quote. Expedited Shipping (38.92 USD or less) Sent with UPS Worldwide Saver. Includes tracking and delivery in 2–3 business days. For many Canadian destinations, the shipping may only cost 34.62 USD. Add items to your cart and click "request a total" to get the most accurate shipping quote. Buyers in Mexico Economy Shipping ($15.36) Sent with Pirate Ship Simple Export Rate (Asendia). Delivery in 1–3 weeks. Sometimes includes tracking, but this seems to vary. Standard Shipping ($36.06) Sent with UPS Standard. Includes tracking and delivery in 1–2 weeks. Expedited Shipping ($38.13) Sent with UPS Worldwide Saver. Includes tracking and delivery in 3–4 business days. Other International Buyers Economy Shipping ($15.36) Sent with Pirate Ship Simple Export Rate (Asendia). Delivery in 1–4 weeks. Tracking is available for: Australia, Austria, Belarus, Belgium, Brazil, Bulgaria, Colombia, Croatia, Czech Republic, Denmark, Estonia, Finland, France, Georgia, Germany, Gibraltar, Greece, Hong Kong, Hungary, Iceland, India, Indonesia, Ireland, Israel, Italy, Japan, Lebanon, Lithuania, Luxembourg, Malaysia, Malta, Netherlands, New Zealand, Norway, Poland, Portugal, Romania, Russia, Saudi Arabia, Serbia, Singapore, Slovakia, Slovenia, South Korea, Spain, Sweden, Switzerland, Taiwan, Thailand, Turkey, United Arab Emirates, United Kingdom, Vietnam Standard Shipping ($19.87–$25.82) Sent with USPS First-Class Package International. Delivery times vary by destination country. Tracking is available for: Australia, Belarus, Belgium, Croatia, Cyprus, Denmark, Estonia, Finland, France, Georgia, Germany, Gibraltar, Greece, Hong Kong, Hungary, Iceland, India, Indonesia, Ireland, Israel, Italy, Japan, Lebanon, Lithuania, Luxembourg, Malaysia, Malta, Netherlands, New Zealand, Poland, Portugal, Romania, Singapore, Slovakia, South Korea, Sweden, Switzerland, Thailand, Turkey, United Kingdom Expedited Shipping ($32.80–$64.51) Sent with UPS Worldwide Saver. Includes tracking and delivery in 3–4 business days. More Prototyping Adapters SOT-23, SOT-323 (SC-70), and SOT-523 combo, with rear cap footprints SOT-23-6 & SOT-23-5 (SOT-26 & SOT-25), with rear cap footprints SOT-363 & SOT-353 (SC-70-6 & SC-70-5), with rear cap footprints SOT-563 & SOT-553, with rear cap footprints TSSOP-16 0.65 mm pitch & SSOP-16 0.635 mm pitch, with some cap footprints Thanks for taking a look!
