6 String Solar PV Combiner Box 15A Circuit Breaker for Solar Panel Plastic

Name: 6 String Solar PV Combiner Box 15A Circuit Breaker for Solar Panel Plastic
SKU: 366314172336
Price: 102.26 USD
Availability: InStock

$51.13

$102.26 -50%

Brand Unbranded

Condition New

Item ID 366314172336

Fearure!	Stable performance, durable
Brand	Unbranded
Color	White
Material	ABS, PC
Style	Modern
Circuit Breaker Type	Standard
Mounting Type	Wall Mount
Operating Temperature	-30~70℃/-22~158℉
Input	6 Strings
Output	1 String
Number Of Poles	6
Current Rating	63A
Number Of Max. Connection PV Array	6
Max. Input Current of Single PV Array	15A
Total Input Current of PV Array	90A
Max Input Voltage of Single PV Array	1000V
Max Output Voltage	600V
Protection Grade	IP65
Relative Humidity	0-95%, No Condensation
Cooling Method	Natural Cooling
Number of Surge Protection Devices	1
Surge Protection Device	40KA, 600V
Number of Circuit Breakers	1
Circuit Breaker	63A, 550V
Product Size	271539cm/10.65.915.35inch
Package Size	352515cm/13.789.845.9inch
Net Weight	3.2kg/7.05 lbs
Gross Weight	3.5kg/7.7 lbs
Type	PV Combiner Box
Application	industrial
Features	Waterproof
Resistance Properties	Dustproof
Current Output	600V
Voltage	600V-1000V

Check the listing for details. 6 String Solar PV Combiner Box 15A Circuit Breaker for Solar Panel Plastic. Color: White, Condition: New. Listed at 102.26 USD. The PV combiner box is made of high-quality ABS and PC, so it is strong and durable. It can make the photovoltaic system at its best and increase output power. It features 6 strings with 15A rated current fuse, a surge protection device, and a 550V 63A circuit breaker, so it is safe to use and will be your ideal choice.
