#80-2 Duplex Double Strand Roller Chain x 10 feet + 2 Connecting Links

Name: #80-2 Duplex Double Strand Roller Chain x 10 feet + 2 Connecting Links
SKU: 305444578612
Price: 119.95 USD
Availability: InStock

$59.98

$119.95 -50%

Condition New

Item ID 305444578612

Return shipping will be paid by	Seller
All returns accepted	Returns Accepted
Item must be returned within	30 Days
Refund will be given as	Money Back
MPN	RC-#80-2/10FT
Brand	PGN Bearings
UPC	810135402767
Manufacturer Part Number	RC-#80-2/10FT

Check the listing for details. #80-2 Duplex Double Strand Roller Chain x 10 feet + 2 Connecting Links. Condition: New. Listed at 119.95 USD. ANSI Chain No.: #80-2 Lenght: 10 feet Pitch (P): 1 inch (25.4 mm) Roller Diameter (d1 max): 0.62 inch (15.88 mm) Width Between Inner Plates (b1 min): 0.62 inch (15.75 mm) Pin Diameter (d2 max): 0.31 inch (7.92 mm) Pin Lenght (L max): 2.46 inch (62.7 mm) Pin Lenght (Lc max): 2.53 inch (64.3 mm) Inner Plate Depth (h2 max): 0.94 inch (24.00 mm) Plate Thickness (T max): 0.12 inch (3.25 mm) Transversal Pitch (Pt): 1.15 (29.29 mm) Ultimate Tensile Strenght (Q min): 113.40/25773 kN/LB Average Tensile Strenght (Qo): 141.8 kN Weight (q): 5.15 lb/ft (2.336 kg/m)
