Check the listing for details. ADF5355 Colour Touch Screen Module VCO Microwave Frequency Synthesizer PLL pc66. Condition: New. Listed at 153.20 USD. Description ADF5355 Colour Touch Screen Module VCO Microwave Frequency Synthesizer PLL Module Features: - ADF5355 High frequency signal source colour screen module - ADF5355 PCB beautiful appearance - Output frequency range:A+、A-output:250M-6.8G,B output (Double A frequency output)6.8G-13.6G； -A output terminals output frequency resolution is 10Khz. - Power supply method:5V power supply,it can be directly charged by USB. -Colour screen display,touch screen operation,you can achieve point frequency and sweep frequency (Note:Don't tear off the protective film on the display screen.Because the touch screen is resistance screen and scratching will causes the touch functions disabler ) - The module has save function and it can storage the setting parameters. - Module actual measured waveform 500M,1Ghz,2Ghz,3Ghz,4Ghz,5Ghz,6Ghz,7Ghz,7.8G, - Module application： - Wireless Infrastructure (W-CDMA,TD-SCDMA,WiMAX,GSM,PCS,DCS,DECT) - Point to point/point to multi-point Microwave link - Satellite/V-SAT - Test equipment / instrument - Clock generation Chip description: - ADF5355 combines with external loop filter and outer reference frequency to use.It can achieve decimal N frequency division or round number N frequency division phase-locked loops (PLL) frequency synthesizer.The microwave broadband VCO deign achieves 6.8 GHz~13.6 GHz working frequency allowed in a RF output.A series of frequency divider for other frequency output can achieve 54 MHz~6,800 MHz working frequency. - ADF5355 has integrated VCO and the fundamental output frequency range is 3400 MHz~6800 MHz.In addition,VCO frequency can be conducted 1、2、4、8、16、32 or 64 frequency division.So the user can produce 54MHz RF output frequency.For the requiring isolation applications,RF output stage can be mute.The mute function can be controlled both through pins and software. - All the on-chip register are controlled through simple three-linear interface.ADF5355 uses 3.15 V~3.45 V analog as well as digital power to work with 4.75 V~5.25 V charge pump and VCO power supply.Besides,ADF5355 has built-in hardware and software power saving mode. - RF output frequency range:54 MHz~13,600 MHz decimal Fractional-N Frequency Synthesizer and round number N frequency division synthesizer - High resolution 38 bits modulus - The working frequency has rised up to 125 MHz Phase Frequency decetor (PFD) - Reference frequency is up to 600 MHz - Within −40°C~+85°C range maintain frequency locking. - Low phase noise voltage controlled oscillator (VCO) - Programmable 1/2/4/8/16/32/64 frequency division output - Analog and digital power supply:3.3 V - Charge pump and VCO power supply:5 V (typical value) - Logical compatibility:1.8 V - Programmable dual modulus prescaler:4/5 or 8/9 - Programmable output power - RF output mute function - Analog and digital locked detector Note:The above is chip description not the module function description. Package List: - 1 x ADF5355 Module - 1 x USB wire Attention:We provide PDF schematic diagram,based on STM32 ADF5355 buttom-level driver and other dates,not provide source program. Payment Terms 1.We accept PayPal only. 2.All major credit cards are accepted through secure payment processor PayPal. 3.Payment must be received within 7 business days of auction closing. 4.We ship to your eBay or Paypal address. Please make sure your eBay and Paypal address is correct before you pay.Shipping Terms - For remote regions, we will charge your extra shipping costs. Usually it cost about 35USD-50USD. We will contact you after your payment. Thanks for your understanding.Return Terms 1. If you receive defective item, please kindly notify us within 14 days. We will guide you the returning instruction for replacement or refund. 2. If you purchased in improper condition, please NOTE that the sipping and handling fee will not be refund, all return shipping fee should paid by the buyer unless item DOA. 3. We reserve the right to refuse any returns for objective reasons.Custom Duties & Taxes 1. Import duties, taxes, and charges are not included in the item price or postage cost. These charges are the buyer's responsibility. 2. Avoiding some unnecessary trouble, please check with your country's customs office to inform us what we should declare its value before shipping.Feedback 1. If you are dissatisfied for any reason, please don't be quick to leave us neutral or negative feedback. We work hard to make sure EVERY CUSTOMER 100% SATISFIED and resolve any problem for you and always leave positive feedback to all our customers. 2. If you are satisfied with the product you received, please kindly leave us a positive feedback and 5 star DSR. If there is any problem of your order, please feel free to contact us firstly, we are responsible and credible seller, will follow it for you asap.
