Check the listing for details. Allen & Heath DX168 16-In x 8-Out Portable Connectivity Expander with ethercon. Condition: New. Listed at 1899.00 USD. The DX168 is a rugged, portable expander for adding remote I/O to a dLive S Class or dLive C Class system. Each DX168 features 16 mic preamps with independent Phantom Power LED indicators, plus 8 XLR line outs. Up to 6 DX168 units can be connected to a dLive system – 4 via the MixRack and 2 via the Surface – allowing up to 96 remote inputs and 48 remote outputs in addition to those provided by the MixRack and Surface. The DX168 connects via a single Cat5e cable to the dLive Surface, MixRack or upstream DX168 via a secure ethercon port. A second locking ethercon port is provided for redundant connection to compatible hardware, or for daisy-chaining to a downstream DX168 for additional remote I/O. The Expander’s rugged design, with hard-wearing rubber bumpers, allows it to be placed directly on the stage floor during performances. Weighing in at just 4.8kg and featuring a sturdy carry handle, the DX168 offers the convenience and portability needed in rental, education, houses of worship and many other environments. An optional 4U rack mounting kit is available which allows installation in industry standard 19-inch racks.Allen & Heath DX168 Features:16 mic preamps on XLR with phantom power status LEDs8 XLR line outsCompatible with dLive S Class and dLive C Class hardwareCascade mode allows daisy-chaining of 2 DX168 Expanders for additional I/OAllen & Heath DX168 Specifications:InputsXLR Mic/Line Inputs: Balanced, +48V Phantom PowerMic/Line Preamp: Fully recallableInput Sensitivity: -60 to +15dBuAnalogue Gain: +5 to +60dB, 1dB stepsPad: -20dB Active PADMaximum Input Level: +30dBu (PAD in)Input Impedance: >4k Ohm (Pad out), >10kOhm (Pad in)Mic/Line Channel noise: 22-22 kHz, Direct Out @ unbalanced outMic EIN: -127dB with 150Ohm sourceMic/Line Channel THD+N: 22-22 kHz, Direct Out @ unbalanced outOutputsXLR Outputs: Balanced, Relay protectedOutput Impedance:Nominal Output: +4dBu = 0dB meter readingMaximum Output Level: +22dBuResidual Output Noise: -92dBu (muted, 20-20kHz)Operating Temperature: 0 deg C to 35 deg C (32 deg F to 95 deg F)Mains Power: 100-240V, 50/60 Hz, 20W max
