Check the listing for details. Antenna Analyzer Tester N1201SA for UV RF Vector Impedance. Condition: New. Listed at 138.10 USD. Antenna Analyzer Tester N1201SA for UV RF Vector ImpedanceWelcome contact for available wholesale price, thank you!DESCRIPTION Features:* This instrument has four interfaces: single point measurement, scanning, information, correction and calibration* By default, the enters the single-point measurement interface upon startup.* Aluminum alloy shell to extend service life.* Note: For user convenience, each calibration correction option will automatically change to user calibration. At the same time, in order to ensure the integrity of the calibration, during the calibration process, there is an automatic shutdown function when a fault occurs, and the power is always turned on.Startup and shutdown:* Hold down the CTRL key without pressing the power switch button.* When the power is on, press and hold (more than 2S) the switch button. After releasing it, the instrument will shut down.* When the power is on, press and hold (more than 2S) the switch button. After releasing it, the instrument will shut down.Recommendations for use:* In order to ensure the accuracy of measurement and calibration, the instrument must be warmed up for at least 15 minutes.* Try to use high-quality RF cables and connectors.* Those marked with calibration cables can be used directly without calibration.* The test cable process affects the measurement accuracy. It is recommended not to choose a test cable that is too long when possible.* Before measuring and calibrating, please make sure you are not in a strong wireless signal to avoid interference and inaccurate measurements.* If you don’t understand the impedance measurement itself, you can refer to the instructions and tutorials of the vector network analyzer. This instrument is equivalent to a single-port vector network analyzer.Specification:Model: PS100Working frequency: 137.5MHz~2700MHzStep frequency: 1kHzDisplay: 2.4-inch TFT, resolution 320*240 (QVGA)Power consumptionCharging current: 400mACharging port: USBAutomatic shutdown: can be set for 5-60 minutesMeasured parameters: impedance, reactance, SWR and S11Resolution: 4 digit readingFrequency accuracy: Connector: SMA-KImpedance measurement range: 1Ω~1000Ω@frequency 1Ω~300Ω @frequency>1300MHz (absolute value of impedance)Standing wave measurement range: 1~65@frequency 1~10@frequency>1300MHzS11(dB) measurement range: 0dB to -50dBError (single point measurement): For impedance: For standing waves: For S11: 0.1dB/5° (0dB to -10dB) For (dB/°): 1dB/10° (-10dB to -20dB); 5dB/20° (-20dB to -40dB)Directivity: Scan points: 280Output level: -18dBmWorking temperature: 0℃ to 40℃Atmospheric pressure: 860hPa~1060hPa ESTIMATED DELIVERY TIME We will ship within 1-5 business days after payment. - Economy: 15-60 days - Standard: 10-35 days - Expedited: 4-7 days Note: Average delivery time for reference only, actual time varies for different countries and related to uncontrollable factors such as weather, natural disasters and pandemic. WARRANTY - Exchange/replace item within 30 days counting from the day you receive merchandise.- Buyer pay the return shipping cost. - Exchange/replace item should be new. Import Duties Our selling price does NOT include your import duties & fess charged by customs, please advise how much value we can show on invoice for expedited shipping.CONTACT US If you have any questions regarding the transaction, before leaving any feedbacks, please tell us and give us an opportunity to find a solution, thank you!
