| Brand | Atomos |
|---|---|
| MPN | ATNINJATX |
| Model | Atomos ATNINJATX |
| Type | Video Monitor |
| Panel Type | IPS-Type LCD |
| Display Size | 5.2 / 13.2 cm |
| Native Resolution | 1920 x 1080 |
| Aspect Ratio | 16:9 |
| Touchscreen | Yes |
| Maximum Brightness | 1500 nits / cd/m2 |
| Color Support | 1.07 Billion Colors (8-Bit+FRC) |
| HDR Support | Yes: Hybrid Log Gamma |
| Color Gamut | 100% Rec. 709 |
| LUT Support | Yes |
| Image Controls | Anamorphic De-Squeeze, Blue Only, False Color, Focus Peaking, Image Flip, OSD Flip, RGB Parade, Scre |
| Antenna I/O | 3x RP-SMA |
| Video I/O | 1 x HDMI 2.0 Input 1 x HDMI 2.0 Output 1 x BNC (12G-SDI) Input 1 |
| Embedded Audio | HDMI/IP/NDI/SDI/USB |
| Audio I/O | 1x 1/8 / 3.5 mm Input 1x 1/8 / 3.5 mm Headphone Output |
| Built-In Speaker | No |
| Power I/O | 1x USB-C (16.8 VDC) Input |
| Other I/O | 2x USB-C Input/Output [Shared with Firmware/LUT Upload/Record/Pow |
| Media/Memory Card Slot | Single Slot: CFexpress Type B [Record/LUT/Firmware] |
| Wi-Fi | Wi-Fi 6E (802.11ax) |
| Bluetooth | Yes |
| Mobile App Compatible | Yes: iOS Only App Name: AtomRemote |
| Video Format | HDMI (8/10/16-Bit 4:2:2) 8K Raw: 30 6K Raw: 60 3.5K Raw: 60 DCI 4 |
| Video Signal Conversion | HDMI to SDI SDI to HDMI |
| Audio Format | 24-Bit |
| Wireless Video Compression | Compressed |
| Timecode Support | Yes |
| Pulldown Conversion | 2:2, 3:2 |
| Camera Trigger | SDI, HDMI |
| Pre-Roll Record | Full HD: 8 Seconds 4K: 2 Seconds |
| Encoding Formats | x DNxHD 36, 145, 220x DNxHR HQ, HQX, LB, SQ ProRes 422, 422 HQ, LT, Raw, Raw HQ H.265 420, 422, HQ |
| Maximum Audio Tracks | 8 |
| Metadata Tagging | Yes |
| Reference Input | No |
| Input Power | 6.2 to 16.8 VDC |
| Battery | 1x L-Series Mount on Fixed Plate |
| Power Consumption | 30 W |
| Tripod/Accessory Mounting | 1x ARRI Anti-Twist 1/4-20 2x 3/8-16 Female |
| Operating Conditions | Up to 104°F / 40.0°C |
| Material of Construction | Aluminum, Plastic |
| Dimensions | 5.9 x 3.6 x 1.4 / 151 x 92 x 36 mm |
| UPC | 814164023184 |
Check the listing for details. Atomos Ninja TX 5.2" Camera to Cloud Monitor/Recorder. Condition: New. Listed at 999.00 USD. The 8/10-bit color processing, HDR support, Rec. Model Atomos ATNINJATX. Type Video Monitor. Native Resolution 1920 x 1080. 1x Antenna Tip Set (Black, White, Yellow, Green, Red). 1x Antenna Cap Set. Flash & Lighting.
