| Restocking Fee | No |
|---|---|
| Return shipping will be paid by | Buyer |
| All returns accepted | Returns Accepted |
| Item must be returned within | 30 Days |
| Refund will be given as | Money back or replacement (buyer's choice) |
| Test frequency: | 100Hz,120Hz,1KHz, 10KHz |
| DCR mode | √ |
| measuring range | L：0.000μH～2000H，C：0.000pF～20.000mF，R：0.0001Ω～200.00MΩ |
| Basic Accuracy | 0.20% |
| Calibration function | Open circuit calibration and short circuit calibration |
| Test level: | 0.1Vrms、0.3Vrms、0.6Vrms 1Vrms |
| Product | Digital LCR Meter |
| MPN | 202309111125 |
| Brand | CNYST |
| Form Factor | Handheld |
| Internal offset | 0-500 mV adjustable, 1 mV step. |
| Display digit | Main parameters: 5 bits, secondary parameters: 5 bits |
| Model | Digital LCR Meter |
| Screening function | The limit range of screening can be set to 1%-50% |
| Country/Region of Manufacture | China |
| Measurement parameters | Main parameters: L/C/R/Z, sub-parameters: X/D/Q/theta/ESR |
| Measurement display speed | 1/s (slow), 2/s (medium), 4/s (fast) |
| Electrolytic capacitor mode | √ |
| Display | 2.8 inch TFT LCD |
Check the listing for details. Digital LCR Meter Handheld Bridge Capacitance Inductance Meter 100Hz-10kHZ. Condition: New. Listed at 258.00 USD. Digital LCR Meter Handheld Bridge Capacitance Inductance Meter 100Hz-10kHZProduct Features¤ The highest measuring frequency is 100kHz, and the stepping frequency is continuously adjustable at 1Hz;¤ Supporting DC Resistance and Electrolytic Capacitance Measurement;¤ Internal bias voltage output (10mV-500mV);¤ Automatic Recognition of Component Measurement;¤ Support screening and deviation measurement;¤ 2.8-inch TFT display, 4-bit semi-display;¤ USB communication interface;¤ Large capacity lithium battery power supply;¤ Support SCPI protocol;¤ Provide system settings, can configure language, buzzer, screen brightness and so on according to their own requirements;¤ The basic measurement accuracy is 0.2%;¤ Adjustable measuring speed, manual and automatic range;¤ Short circuit correction with open circuit;¤ Provide multiple test ports.Main technical indicatorsTechnical DataTest frequency100Hz,120Hz,1KHz, 10KHzBasic accuracy0.002Display2.8 inch TFT LCDDisplay digitMain parameters: 5 bits, secondary parameters: 5 bitsMeasurement parametersMain parameters: L/C/R/Z, sub-parameters: X/D/Q/theta/ESRElectrolytic capacitor mode√DCR mode√measuring rangeL：0.000μH～2000H，C：0.000pF～20.000mF，R：0.0001Ω～200.00MΩMeasurement display speed1/s (slow), 2/s (medium), 4/s (fast)Internal offset0-500 mV adjustable, 1 mV step.Test level0.1Vrms、0.3Vrms、0.6Vrms 1VrmsCalibration functionOpen circuit calibration and short circuit calibrationScreening functionThe limit range of screening can be set to 1%-50%, of which the fixed points are 1%, 5%, 10%, 20%.Deviation measurementUsed to compare the percentage of deviation between the component and the nominal value set and displayOtherAdjust backlight brightness, automatic shutdown time can be set, Chinese and English optional, USB Device communication Standard accessoriesMini-USB data Wires;Power adapter;Short circuit chip;Red&black rubber plug;Large capacity lithium batteryKelvin test clip Optional accessories SMD testing cl
