| Restocking fee | No |
|---|---|
| Return shipping will be paid by | Seller |
| Returns Accepted | Returns Accepted |
| Item must be returned within | 30 Days |
| Origin | Mainland China |
| Brand | Unbranded |
| Usage | Home DIY |
| Type | Other |
| is_customized | No |
| MPN | Does not apply |
| Model Number | DS-200 |
Check the listing for details. Dryer Dew Point -40°C Air Compressor Small Compressed Air Dehydration Dryer 220V. Condition: Brand New. Listed at 634.02 USD. eBay DS-200 Rated voltage: 220V/AC Rated current: 0.1A Rated power: 15W Rated flow: 200L/min Outlet dew point: ≤-40℃ Rated pressure: 5-8Bar Air inlet: internal teeth G1/4 Air outlet: inner teeth G1/4 Inlet temperature: ≤30℃ Desorption time: 30-999s (adjustable) Back pressure time: 0-999s (adjustable) Dimensions: length 230MM* width 89MM* height 361MM Mounting hole size: length 217MM* height 70MM hole 6.5MM The adsorption dryer uses advanced chemical technology. Its principle is to use the difference between the volume of moisture and air molecules in the saturated compressed air. The special molecular sieve for gas purification is used to filter out the saturated water vapor in the compressed air, which can easily remove the water molecules. Adsorbed in the molecular sieve particles, and then use the regeneration method to restore the molecular sieve, the compressed air dew point can easily reach below -40°C. The adsorption dryer achieves the drying effect through "pressure change" (principle of pressure swing adsorption). Since the air's ability to hold water vapor is inversely proportional to its pressure, a portion of its dried air (called regeneration air) decompresses and expands to atmospheric pressure. This pressure change makes the expanded air drier, and then lets it flow through the unconnected air flow. The desiccant layer to be regenerated (that is, the drying tower that has absorbed enough water vapor), the dry regeneration gas sucks out the moisture in the desiccant, and takes it out of the dryer to achieve the purpose of dehumidification. The two towers work in a cycle without a heat source, and continuously provide dry compressed air to the user's gas system.
