Check the listing for details. Extron RGB 550, Gray - NEW IN BOX. Condition: New. Listed at 79.95 USD. Normal 0 false false false EN-US X-NONE X-NONE Extron RGB 550, Gray - NEW IN BOX Please Read NOTE 1 Below. Extron Electronics, known as Extron, is a manufacturer of professional audiovisual equipment. It is headquartered in Anaheim, California. Extron is a global leader in the manufacturing of high-quality audio / visual solutions that are reliable and that last. Video input Number/signal type 1 analog RGBHV, RGBS, RGsB, RsGsBs Connectors — RGB 500, RGB 500 Dual, RGB 500 EC, RGB 508, RGB 508 EC, RGB 500 AKM 1: 9-pin D male, MBC/LBC cable or buffer Connectors — RGB 550, RGB 550 Dual, RGB 550 EC, RGB 558, RGB 558 EC, RGB 550 AKM 1: 15-pin HD male (Mac and Sun/SGI to VGA adapter cables are available.) Nominal level(s) Analog: 0.3V to 1.5V p-p Minimum/maximum level(s) Analog: 0V to 1.5V p-p Impedance 75 ohms or High Z, switchable (set to 75 ohms if no local monitor is connected) Horizontal frequency Autoscan 15 kHz to 130 kHz Vertical frequency Autoscan 30 Hz to 120 Hz Return loss -30dB @ 5 MHz Maximum DC offset 4.0V Video throughput Gain AKM models (0.7V) unity, (0.8V) 50%, (0.9V) 100% All other models Unity (0.70V p-p), (0.725V p-p) 50% peaking, (0.75V p-p) 100% peaking Bandwidth 300 MHz (-3dB) Video output Number/signal type 1 analog RGBHV, RGBS, RGsB Connectors — All models 5 BNC female Connectors — RGB 550, RGB 550 Dual, RGB 550 EC, RGB 558, RGB 558 EC, RGB 550 AKM 1: 15-pin HD female for buffered local monitor output Nominal level AKM models 0.7V p-p, 0.8V p-p, 0.9V p-p All other models 0.70V p-p, 0.725V p-p, 0.75V p-p Impedance 75 ohms Return loss -30dB @ 5 MHz Sync Input type RGBHV TTL (±), RGBS TTL (±), RGsB 0.3V (-), RsGsBs 1.3V (-) Output type RGBHV (±), RGBS(±), RGsB (-) Input level 2V to 5.5V p-p with ±0.3VDC offset (max.) Output level 4V to 5V p-p Input impedance 10 kohms Output impedance 75 ohms Max. input voltage 5.7V p-p Max. propagation delay 48 nS Max. rise/fall time 3.5 nS Polarity — AKM models RGBHV Polarity follows input when RGBHV is input and the sync polarity switch is set to Off.: Sync polarity is negative if the sync polarity switch is set to On. RGBS, RGsB Negative Polarity — All other models RGBHV: Polarity follows input when RGBHV is input and the bottom panel sync polarity jumper is set to follow (pin 1 jumpered to pin 2). Sync polarity is negative if the sync polarity jumper is set to negative (pin 2 jumpered to pin 3). RGBS, RGsB Negative Audio input Number/signal type 1 PC level stereo, unbalanced Connectors 1: 3.5 mm stereo jack, 2 channel; tip (L), ring (R), sleeve (ground) Impedance 10 kohms, DC coupled Minimum level: 100mV Maximum level +8.5dBu,: (unbalanced) @ stated %THD+N Audio throughput Gain Unbalanced 0dB,: balanced +6dB Frequency response ±0.05dB @ 20 Hz to 20 kHz THD + Noise 0.03% @1 kHz,: 0.3% @ 20 kHz at rated maximum output drive S/N >90dB, output 14dBu, balanced Stereo channel separation >95dB @ 1 kHz to 20 kHz Audio output Number/signal type 1 stereo (2 channel), balanced/unbalanced Connectors 3.5 mm stereo captive screw terminal, 5 pole, for left and right output Impedance 50 ohms unbalanced,: 100 ohms balanced Gain error ±0.1dB channel to channel Drive (600 ohm) > +14dBu, balanced at stated %THD+N General Power 12 to 24VAC or VDC, 0.5 A, 5 watts, external (Order the power supply separately, part #70-055-01.) Temperature/humidity Storage -40° to +158°F (-40° to +70°C) / 10% to 90%, non-condensing Operating +32° to +122°F (0° to +50°C) / 10% to 90%, non-condensing Rack mount No Furniture mount Yes, or wall mount, with included hardware Enclosure type Metal Enclosure dimensions — RGB 500, RGB 550 Faceplate 4.50" H x 4.50" W (11.43 cm H x 11.43 cm W): (2-gang) Interface enclosure 2.50" H x 3.70" W x 1.75" D (6.35 cm H x 9.40 cm W x 4.45 cm D) Enclosure dimensions — RGB 500 Dual, RGB 508, RGB 550 Dual, RGB 558 Faceplate 4.50" H x 8.20" W (11.43 cm H x 20.83 cm W): (4-gang) Interface enclosure 2.50" H x 3.70" W x 1.75" D (6.35 cm H x 9.40 cm W x 4.45 cm D) Enclosure dimensions — RGB 500 EC, RGB 550 EC Faceplate 3.15" H x 3.93" W: (8.00 cm H x 9.98 cm W) Interface enclosure 2.50" H x 3.70" W x 1.75" D (6.35 cm H x 9.40 cm W x 4.45 cm D) Enclosure dimensions — RGB 508 EC, RGB 558 EC Faceplate 3.15" H x 7.69" W: (8.00 cm H x 19.53 cm W) Interface enclosure 2.50" H x 3.70" W x 1.75" D (6.35 cm H x 9.40 cm W x 4.45 cm D) Enclosure dimensions — RGB 500 AKM, RGB 550 AKM Interface 3.08" H x 8.13" W x 1.62" D (7.82 cm H x 20.64 cm W x 4.12 cm D) Shipping weight RGB 500, RGB 550: 2 lbs (0.9 kg) All other models: 3 lbs (1.4 kg) Vibration NSTA 1A in carton (National Safe Transit Association) Approvals AKM models UL, CE All other models UL, CE, FCC Class A MTBF 30,000 hours Warranty 3 years parts and labor (7.0-030100-D1) NOTE 1 1. This item is new. 2. Due to the highly unscrupulous parts-swappers on eBay, every item is being sold on an “as-is” basis. 3. As much as we would like to do so, we do not control the speed of the shippers. We usually ship the same day as we receive the order. If your package seems to be shipping slow, check the tracking number for progress. Free shipping only applies to the 48 contiguous states. Alaska, Hawaii, Puerto Rico, etc. please contact with your zip code for correct shipping charges.
