Check the listing for details. EXTRON VSC-700 DIGITAL SCAN CONVERTER HIGH RESOLUTION 1900X1200 WITH GENLOCK WRK. Condition: Used. Listed at 499.99 USD. EXTRON VSC-700 DIGITAL SCAN CONVERTER WITH GENLOCK VERY HIGH RESOLUTION UP TO 1900X1200 IN EXCELLENT WORKING CONDITION+ORIGINAL OPERATING MANUAL * The Extron VSC 700 and VSC 700D High Resolution Computer-to-Video Scan Converters combine high performance processing with an expanded feature set designed for easy integration. * They accept computer-video signals at resolutions up to 1920x1200 and simultaneously output a scan-converted video signal as NTSC or PAL composite video, S-video, and component video or RGB video. * In addition, the VSC 700D includes a fourth, SDI serial digital video output. * The VSC 700 and VSC 700D are ideal for use in a wide range of applications, including videoconferencing, video recording, and viewing of computer-video images on an NTSC or PAL monitor or other video display device. * Both models feature Auto-Image™ setup for automatic adjustment of centering, sizing, and filter settings. * Additional key features include zoom control up to 200%, a color bar generator, an LCD display for user-friendly menu navigation, memory presets, and a buffered loop-through for local monitor output. * For broadcast and production applications, the VSC 700 and VSC 700D include video genlock capability for synchronization to an external reference signal. * The VSC 700D adds an SDI output for integration into digital broadcast and production systems. * The VSC 700 and VSC 700D can be controlled via the front panel, RS-232 or RS-422 serial control, or the optional VSC Remote handheld IR remote control. * They are housed in rack-mountable 1U, half rack width enclosures and are equipped with an internal international power supply. * Features: * Input: Female BNC connectors with buffered loop-through * Outputs: RGB or standard definition component video on five BNCs, S-video on 4-pin mini DIN, composite video on female BNC connector, and SDI on female BNC connector - VSC 700D only * Automatically recognizes and converts computer resolutions from 560x384 to 1920x1200 and frequencies to 100 kHz horizontal and 120 Hz vertical * Buffered loop-through — Provides a local monitor output, enabling the computer input signal to be monitored without the need for a separate distribution amplifier. * Three simultaneous outputs — NTSC or PAL standard video is output as composite video, S-video, and component or RGB video. * Optional SDI output — The VSC 700D features a SMPTE 259M- and ITU.R BT-601-compliant SDI serial digital video output that facilitates the integration of computer-video signal sources into digital broadcast and production applications. * Auto-Image™ setup — Saves time by providing calibration of image size, position, clock, and phase adjustments at the touch of a button. * Vertical filtering — Five selectable vertical filters reduce jitter, improve image quality, and help maintain picture detail. * Horizontal filtering — Four selectable horizontal filters prevent aliasing or pixel elimination so that less detail is dropped when the image is scanned from left to right. * Sizing and centering controls — User-friendly positioning is accessible through the front panel for quick and efficient image setup. * Image zoom control and presets — Eight zoom presets are available for recalling size, position, and filtering, enabling the user to quickly zoom in on a certain area of an image. * Input memory presets — Allow the scan converter to automatically recall up to 16 user presets, 60 factory presets, and eight zoom presets. * Each memory location stores filter, size, and centering, or zoom settings for each source which can be recalled instantaneously when switching between different computer-video inputs and resolutions. * Image freeze control — The output video can be frozen using the freeze button on the front panel. * This allows the scan converter to capture a frame of video to display for an extended period of time, even after the source has been removed. * Internal color bar generator — An internally-generated color bar pattern is provided for simplified setup of a display. * The color bar pattern or a black screen can also be set as the default output when no input signal is present. * Video genlock with loop-through — All NTSC and PAL video outputs can be synchronized to an external reference signal for integration into broadcast and production applications. * RS-232 and RS-422 control port — Using serial commands, the VSC 700 and VSC 700D can be controlled and configured via the Extron Windows®-based control program, or integrated into a control system. Extron products use the SIS™ - Simple Instruction Set command protocol, a set of basic ASCII code commands that allow for quick and easy programming. * Optional IR remote control, part # 70-206-01 (Not Included) — The optional VSC Remote handheld IR remote control performs most front panel functions such as image freeze, zoom in and out, size and shift, vertical filter adjustment, and preset selection. * Front panel security lockout — This feature locks out all front panel functions except for input selection; all functions however, are available through RS-232 control. * Rack-mountable 1U, half rack width metal enclosure * Internal universal power supply — The 100-240 VAC, 50/60 Hz, international power supply provides worldwide power compatibility. CONDITIONS & ACCESSORIES * Working Condition: Excellent (Bench Tested Against DOA) * Cosmetic Condition: Very Good W/ Some Scratches * Original Operating Manual In PDF File Via Email * AC Power Cord FEATURES & CONNECTORS: * Video input Number/signal type 1 RGBHV, RGBS, RGsB with 1 buffered loop-through * Connectors * 2 x 5 female BNC (5 for input, 5 for loop-through) * Nominal level 0.7 Vp-p for RGB * Minimum/maximum levels 0 V to 2.0 Vp-p with no offset at unity gain * Impedance 75 ohms * Horizontal frequency Autoscan 24 kHz to 100 kHz * Vertical frequency Autoscan 50 Hz to 120 Hz * Resolution range Autoscan 560 x 384 to 1920 x 1200; 480p, 720p, 1080i, 1080p (RGB only) * DC offset (max. allowable) 2.0 V * External sync (genlock) 0.3 V to 1.0 Vp-p * Video processing * Encoder 10 bit digital * Digital sampling 24 bit, 8 bits per color * Colors 16.8 million * Horizontal filtering 4 levels * Flicker filtering 4 levels * Encoder filtering 4 levels * Video output * Number/signal type 1 RGBHV, RGBS, RGsB, or component video * 1 S-video * 1 NTSC/PAL composite video * Connectors 5 BNC female: RGBHV/RGBS/RGsB/component video * 1 BNC female: SDI component video (VSC 700D only) * (1) 4-pin mini-DIN female: S-video * 1 BNC female: composite video * Nominal level * 1 Vp-p for Y of component video and S-video, and for composite video * 0.7 Vp-p for RGB and for R-Y and B-Y of component video * 0.3 Vp-p for C of S-Video * Minimum/maximum levels * 0.0 V to 0.7 Vp-p (RGB) * 0.0 V to 1.0 Vp-p (component video, G of RGsB) * Impedance 75 ohms * Sync * Input type Autodetect RGBHV, RGBS, RGsB * Output type RGBHV, RGBS, RGsB * Genlock connectors 1 BNC female: genlock input * 1 BNC female: genlock output (terminate w/75 ohms if unused) * Standards NTSC 3.58, PAL * Input level 1.5 V to 5.0V p-p * Output level TTL: 5.0V p-p, unterminated * Input impedance 600 ohms * Output impedance 75 ohms * Max. input voltage 5.0 Vp-p * Polarity Negative * Control/remote — scan converter * Serial control port RS-232 or RS-422, 9-pin female D connector * Baud rate and protocol 9600 baud, 8 data bits, 1 stop bit, no parity * Serial control pin configurations RS-232: 2 = Tx, 3 = Rx, 5 = GND * RS-422: 2 = Tx-, 3 = Rx-, 5 = GND, 7 = Rx+, 8 = Tx+ * IR controller module VSC Remote (Not Included) * Program control Extron's control/configuration program for Windows® * Extron's Simple Instruction Set (SIS™) * General * Power 100 VAC to 240 VAC, 50/60 Hz, 30 watts, internal * Temperature/humidity Storage: -40 to +158 °F (-40 to +70 °C) / 10% to 90%, noncondensing * Operating: +32 to +122 °F (0 to +50 °C) / 10% to 90%, noncondensing * Cooling Convection, no vents * Mounting * Rack mount Yes, with optional 1U, 9.5" deep rack shelf, part # 60-190-01 (RSU 129) or 60-604-01 (RSB 129) (Not Included) * Enclosure type Metal * Enclosure dimensions * VSC 700 1.75" H x 8.75" W x 10.5" D (1U high, half rack wide) (4.4 cm H x 22.2 cm W x 26.7 cm D) * (Depth excludes knobs.) * Product weight * VSC 700 2.8 lbs (1.3 kg) * Shipping weight 5 lbs (3 kg) * Vibration ISTA 1A in carton (International Safe Transit Association) * Regulatory compliance * Safety CE, CUL, UL * EMI/EMC CE, C-tick, FCC Class A, ICES, VCCI * Environmental Complies with the appropriate requirements of WEEE. * MTBF 30,000 hours PAYMENTS & SHIPPING: * PAYPAL * Buyer is required to prepay for item plus $20.00 FedEx Ground (48 lower states only) within 7 days of auction end. * Thanks for bidding. Serious bidder please * Please check out my other auctions. * PLEASE RESOLVE ALL QUESTIONS BEFORE BIDDING.
