| Travel Length**Ballscrew*Compatible motor | 100mm(4 in)---SFU1605---Nema23/Nema 34 Step |
|---|---|
| Brand | TOSEARSTARS |
| MPN | QMF120 |
| Type | Linear Motion System |
| Overall Travel Length | Effective Stroke+9.44inch |
| Country/Region of Manufacture | China |
| Module width | 4.72 inch (120mm) |
| Guide | 2PCS*HGR15 0.59 inch Width(15mm ) |
| Block | 2PCS*HGH15CA |
| Horizontal load(Max) | 220 Ib (100KG) |
| Vertical load(Max) | 110 Ib (50KG) |
| Motor bracket | for 57mm/86mm Stepper; |
| Mobile panel size | 4.72 inch*4.72 inch(120mm*120mm) |
| Slide height | 3.77 inch (96mm) |
| Ballscrew type | SFU1605 |
| Ball screw accuracy | C7 |
| Max.moving speed | 11.8 inch/s (300mm/s) |
| Module material | Aviation aluminum 6061 |
Check the listing for details. Heavy Duty Fully Sealed Ball Screw Slide Table 100-220lb CNC Linear Module Stage. Condition: New. Listed at 197.61 USD. Product Overview Industrial-grade fully enclosed linear slide table with dual HGR15 guide rails and SFU1605 ball screw. Features 100KG horizontal load capacity, 300mm/s max speed, and dustproof aluminum cover for CNC, lab automation, and medical applications. Pre-assembled with motor couplings. Product Feature ✅ Military-Grade Sealing - Integrated dust cover prevents debris ingress in woodworking/CNC environments ✅ Precision Ball Screw Drive - SFU1605 C7-grade screw delivers ±0.05mm positioning accuracy ✅ Heavy-Duty Performance - Dual HGR15 rails support 220lb horizontal load (100KG) ✅ Aviation Aluminum Construction - 6061-T6 alloy with sandblasted oxidation resists corrosion ✅ Flexible Motor Integration - Pre-drilled mounts for 57mm/86mm steppers with coupling kit.
