| Brand | Unbranded |
|---|---|
| Material | FC30 Cast Iron |
| Color | Black, Silver |
| Mounting Required | YES |
| Number of T-Slot | 3 |
| Worm Gear Transmission Ratio | 1:90 |
| Worm Gear Module | 1.5mm/0.06inch |
| Max. Load Capacity (Horizontal) | 100kg/220 lbs |
| Max. Load Capacity (Vertical) | 50kg/110 lbs |
| Indexing Accuracy | 0.05° |
| Graduated Ring of the Handwheel Scale | 4° (A Whole Circle)/30 Small Scales Equal 1° |
| Large Wheel Scale Range | 360° |
| Gross Weight | 12.6kg/27.78 lbs |
| Net Weight | 12.06kg/26.59 lbs |
| Handwheel Diameter | 12.1cm/4.7inch |
| Product Size (Vertical) | 31*10.6*24.2cm/12.2*4.1*9.5inch |
| Package Size | 31.5*26*16cm/12.4*10.24*6.3inch |
Check the listing for details. Horizontal Vertical Rotary Table 3-Slot Rotary Table 360° Rotary Adjustment. Color: Black, Silver, Condition: New – Open box. Listed at 192.68 USD. Specifications Material: FC30 Cast Iron Color: Black, Silver Mounting Required: Yes Number of T-Slot: 3 Worm Gear Transmission Ratio: 1:90 Worm Gear Module: 1.5mm/0.06inch Max. Load Capacity (Horizontal): 100kg/220 lbs Max. Load Capacity (Vertical): 50kg/110 lbs Indexing Accuracy: 0.05° Graduated Ring of the Handwheel Scale: 4° (A Whole Circle)/30 Small Scales Equal 1° Large Wheel Scale Range: 360° Gross Weight: 12.6kg/27.78 lbs Net Weight: 12.06kg/26.59 lbs Handwheel Diameter: 12.1cm/4.7inch Product Size (Vertical): 31*10.6*24.2cm/12.2*4.1*9.5inch Package Size: 31.5*26*16cm/12.4*10.24*6.3inch Package Included 1* 3-slot Rotary Table Other Accessories for Installation.
