| Country of Origin | United States |
|---|---|
| Brand | findmall |
| MPN | TL29268Q |
| Chain Pitch | 1.0 inch (25.400 mm) |
| Chain Length | 10 ft |
| Chain Size | #80H |
| Roller Diameter (d1 max) | 0.625 inch (15.88 mm) |
| Width Between Inner Plates (b1 min) | 0.620 inch (15.75 mm) |
| Custom Bundle | No |
| Bundle Description | No |
| Modification Description | No |
| Average Tensile Strenght (Qo) | 71.4 kN |
| Country/Region of Manufacture | Unknown |
| Ultimate Tensile Strenght (Q min) | 56.70/12886 kN/LB |
| Manufacturer Warranty | 6 months |
| Feature | ESCP |
| Chain Type | Roller Chain |
| Features | Roller Chain |
| Model | Roller Chain |
| Modified Item | No |
Check the listing for details. Labwork Roller Chain #80H Heavy Duty 10 Feet + Free Connecting Link 1 Connector. Condition: New, Made in United States. Listed at 44.20 USD. Description： -ANSI Chain No.: #80H -Lenght: 10 Feet -Pitch (P): 1.0 Inch (25.400 mm) -Roller Diameter (d1 Max): 0.625 Inch (15.88 mm) -Width Between Inner Plates (b1 Min): 0.620 Inch (15.75 mm) -Pin Diameter (d2 Max): 0.311 Inch (7.92 mm) -Pin Lenght (L Max): 1.425 Inch (36.20 mm) -Pin Lenght (Lc Max): 1.484 Inch (37.70 mm) -Inner Plate Depth (h2 Max): 0.944 Inch (24.00 mm) -Plate Thickness (T Max): 0.157 Inch (4.00 mm) -Ultimate Tensile Strenght (Q Min): 56.70/12886 kN/LB -Average Tensile Strenght (Qo): 71.4 kN -Weight (q): 2.083 lb/ft (3.1 kg/m) Package Include： 1*80H Heavy Duty Roller Chain x 10 Feet+1 Connector W/o Product Instruction .
