| Restocking Fee | No |
|---|---|
| Return shipping will be paid by | Buyer |
| All returns accepted | Returns Accepted |
| Item must be returned within | 30 Days |
| Refund will be given as | Money back or replacement (buyer's choice) |
| Frequency Range | Current：1nA~20mA Resistance：1kΩ~325GΩ |
| Basic Accuracy | 1% |
| Custom Bundle | No |
| Measurement Functions | LCR meter |
| Product | LCR Meter |
| MPN | 2022 |
| Charging Timer | 999.9s |
| Comparator | 30 sets records , OK/NG |
| Charging Current | Auto & Manual |
| Form Factor | LCR Meter |
| Beep | OK, NG, set for volume & off |
| Accuracy | 1% |
| Output Impedance | LCR Meter |
| Speed | 55 times/s, 15 times/s, 3 times/s |
| Dimension & Weight | 264 x107x350 mm |
| Parameters | Leakage current & Insulation Resistance |
| Max Reading | 9999 |
| Range | Auto & Manual |
| Modified Item | No |
| California Prop 65 Warning | LCR Meter |
| Result Display | show, current, resistance,Peak and sorting results |
| Brand | VTSYIQI |
| Model | LCR meter |
| Country/Region of Manufacture | China |
| Output Voltage | Digital controll 1V~650VDC |
| Interface | RS-232, Handler interface |
Check the listing for details. Leakage Current Meter Insulation Resistance Tester for Capacitor 1nA~20mA. Condition: New. Listed at 779.92 USD. Leakage Current Meter Insulation Resistance Tester for Capacitor 1nA~20mA Introduction:Leakage Current/IR Meter provides DC 1~ 650 V voltage source. Mainly used for electrolytic capacitor leakage current testing, and aluminum-foil withstand voltage testing. And also can be used for active voltage checking or leakage current testing of absorber, Zener diode, and Neon lamp etc. RS232C interface and Handler interface, optional USB interface, high speed (55/second) and stable measurement capabilities enable the AT680 can be used for both component evaluation on the production line and fundamental leakage current testing for benchtop applications. Feature:High brightness, ultra-clear four-color VFD display, multiple parameters are displayed at the same time.The charging test is automatically switched.Peak hold function.Full range open circuit clear function.Comparator output: the sorting result can be output through RS232C or Handler interface.Beep: beep switch.Adjustable beep and display: Users can set the GD/NG beep and trigger mode according to their needs: internal trigger, manual trigger, external trigger and remote trigger.Adjust the display brightness.Optional foot switch. Specification:ParametersLeakage current & Insulation ResistanceAccuracy1%Output VoltageDigital controll 1V~650VDCMeasurement RangeCurrent：1nA~20mA Resistance：1kΩ~325GΩMax Reading9999RangeAuto & ManualCharging CurrentAuto & ManualSpeed55 times/s, 15 times/s, 3 times/s,Result Displayshow, current, resistance,Peak and sorting resultsCharging Timer999.9sComparator30 sets records , OK/NGBeepOK, NG, set for volume & offInterfaceRS-232, Handler interfaceDimension & Weight264 x107x350 mm Applications:Production of electrolytic capacitors.Capacitor inspection.Insulation resistance test of electronic components and equipment.Transistor leakage current detection.Dielectric materials and insulation resistance testing of wires and cables, etc.
