Check the listing for details. Motorola DSR 6401 Multichannel Receiver 582741-001 Single Channel Transcoder. Condition: Used. Listed at 1500.00 USD. Motorola DSR 6401 Multichannel Receiver 582744-001-00 Single Channel Transcoder SPECIFICATIONS L-Band Input Input Frequency 950 - 2150 MHz Input Impedance 75 Ω Input Connectors Eight (8) F-type LNB Power Out 16V DC min/450 mA Port-to-Port Isolation 40 db (minimum) Digital Processing Modulation Modes DVB-S2, 8PSK Turbocodes and DCII QPSK Symbol Rates DVB-S2 3 to 33 Msps 8PSK Turbocodes 3 to 30 Msps DCII QPSK 3.25 to 29.27 Msps FEC Rates DVB-S2/8PSK 3/5, 2/3, 3/4, 5/6, 8/9, 9/10 8PSK Turbocodes 2/3 (1.9), 3/4 (2.05), 3/4 (2.11), 3/4 (2.19), 5/6 (2.30), 8/9 (2.40) DCII QPSK 1/2, 3/5, 2/3, 3/4, 4/5, 5/6, 7/8 Transcoder Inputs Compression Formats MPEG-4 and MPEG-2 HD Resolution 1080i 25/29.97 fps,720p50/59.94 fps SD Resolution 480i 29.97 fps and 576i 25 fps Transcoder Outputs Compression Formats MPEG-2 HD Resolution 1080i 25/29.97 fps,720p50/59.94 fps SD Resolution 480i 29.97 fps and 576i 25 fps Aspect Ratio Conversion (HD down-conversion) 4x3 center-cut, 4x3 letterbox, 14:9 and anamorphic © 2016 ARRIS Enterprises, LLC. All rights reserved. DSR-6400 Commercial Integrated Satellite Receiver/Transcoder SPECIFICATIONS (CONTINUED) Composite Video Output Frequency Response (NTSC) ±0.9 dB, 1kHz–4.2 MHz Output Impedance 75 Ω Output Level 1.0 V p-p ± 10% Connectors Two BNC (one with OSD) Audio Output Output Two stereo pair or four mono Frequency Response ±0.5 dB, 20 Hz to 20 kHz Audio Impedance 600 Ω load Peak Audio Level ±16.0 dBu ± 1.0 dB Connectors Quick disconnect screw terminal Ethernet Management Port Connector RJ-45 Format 10/100BaseT GigE Interface Connector RJ-45 Format 10/100/1000BaseT ASI Interface Format Asynchronous Serial Interface Transmission Byte or packet mode Standard CENELEC EN 50083-9 Connectors BNC (two out, one in) Contact Closures/Cue Tones Number of Contact Closures Four (one alarm) Contact Closure Type Form C Number of Cue Tone Outputs 4 Physical Width 18.9 in (48cm) Depth 24.9 in (63.2 cm) Height 1.65 in (4.2cm) Weight 12.5 lb (5.7 kg) approx Power Input 100-240 VAC, 50-60Hz, 85W max Operating Temperature 0 °C to 40 °C Humidity 95% relative maximum Display Two line, 40-character LCD
