Check the listing for details. National Instruments SC-2040 8 Channel Sampling Differential Amplifier (MIO-16E. Condition: Used. Listed at 499.99 USD. National Instruments SC-2040 8 Channel Simultaneously Sampling Differential Amplifier (For MIO-16E Series DAQ Boards) Comes with a manual and what you see in the pictures. If you don't see it, you probably wont get it. Specifications are from National Instruments and may vary slightly due to upgrades, options, or revisions this unit may or may not have. This unit is sold as-is, untested. The Unit's Serial Number Tag Reads: Model Number: SC-2040 Part Number: 182665A-01 Serial Number: AEC46B CE Marked: Yes Description: The SC-2040 is an eight-channel simultaneously sampling differential amplifier for the National Instruments MIO-16E Series DAQ boards. Each channel provides DIP-switch-selectable gain followed by a track-and-hold amplifier. The track-and-hold amplifiers sample all the inputs at the same time, which is useful for preserving interchannel phase relationships. The MIO-16E can trigger the track-and-hold amplifiers, or you can supply an external trigger source. The SC-2040 is a circuit board assembly that is placed on a workbench or mounted in a 19-in. rack. You can configure teh SC-2040 to draw power from the MIO-16E board or from an external +5 V supply. A red LED indicates when the board is powered on. Input signal leads are attached at screw terminals. Analog Input Specifications: Input Characteristics: Number of Channels: 8 differential Input Signal Ranges: Board Gain (Hardward Selectable):Board Range Max Output Range ±10 V:1±10 V10±1 V100±100 mV200±50 mV300±33.3 mV500±20 mV600±16.67 mV700±14.29 mV800±12.5 mV Input Coupling: DC Max Working Voltage (Signal + Common Mode): Average of 2 inputs should remain within ±7 V of ground Overvoltage Protection: ±30 V powered on, ±15 V powered off Inputs Protected: ACH Transfer Characteristics: Offset Error: Pregain Error After Calibration: ±100 µV max Postgain Error After Calibration: ±2 mV max Gain Error and Non Linearity: Gain (DIP-switch-selectable):Max Gain Error:Max Gain Tempco:Max Nonlinearity:1±0.05%±25 ppm/°C±0.01%10±0.1%±25 ppm/°C±0.01%100±0.2%±45 ppm/°C±0.02%200±0.4%±60 ppm/°C±0.02%300-0.3%, ±0.6%±80 ppm/°C±0.03%5001.0%±100 ppm/°C±0.04%600-0.2%, 1.5%±120 ppm/°C±0.05%700-0.1%, 2.0%±150 ppm/°C±0.06%800-0.3%, 3.0%±200 ppm/°C±0.07% Amplifier Characteristics: Input Impedance: Normal Powered On: 100 GΩ in parallel with 20 pF Input Bias Current: ±100 pA, ±10 mA max Input Offset Current: ±10 pA CMRR: Gain: dB (Min and Typ): Gain = 1 70 dB min, 90 dB typ Gain = 10 87 dB min, 104 dB typ Gain > or = to 100 100 dB min, 110 dB typ Output Range: ±10 V Dynamic Characteristics: Bandwidth: Gain:-3 dB Bandwidth:12 MHz 10 800 kHz 100 500 kHz 200 300 kHz 300 180 kHz 500 120 kHz 600 100 kHz 700 80 kHz 800 70 kHz System Noise: Gain: Filter:1 175 µVrms 10 50 µVrms 100 45 µVrms 200 40 µVrms 300 35 µVrms 500 33 µVrms 600 30 µVrms 700 29 µVrms 800 27 µVrms Noise Spectral Density: Input Noise (Gain = 1): 12 nV/√Hz Output Noise: 85 nV/√Hz Slew Rate: 8 V/µs S/H Characteristics: Measurement:0.012%:0.003%:0.0015%:0.00076%:Track Mode Acquisition Time:7 µs10 µs50 µs1 msHold Mode Settling Time:1 µs1 µs1 µs2 µsHold Step:-5 mV---Droop Rate:±10 mV/s---Aperture Time:250 ns---Interchannel Skew:±50 ns--- Stability: Recommended Warm-Up Time: 15 min Offset Temperature Coefficient: ±(10 + 150/gain) µV/°C Gain Temperature Coefficient: Gain (DIP-switch-selectable): Max Gain Tempco: 1 #25 ppm/C 10 #25 ppm/C 100 #45 ppm/C 200 #60 ppm/C 300 #80 ppm/C 500 #100 ppm/C 600 #120 ppm/C 700 #150 ppm/C 800 #200 ppm/C Power Requirement Specifications: +5 VDC (±10%): 800 mA Total Power Dissipation: 4 W Physical Specifications: Dimensions: 1.8" x 7.9" x 4.9" (4.6 cm x 20.1 cm x 12.4 cm) I/O Connectors: Input: 20-screw terminals Output: 50-pin male ribbon-cable rear connector, 68-pin male ribbon-cable rear connector Environment Specifications: Operating Temperature: 0° to 50°C Storage Temperature: -55° to 150°C Relative Humidity: 5% to 90% noncondensing For Domestic Customers: Packaging, handling, and order processing included in shipping in all domestic shipments as quoted by the shipping calculator. For International Customers there is a $15.00 minimum for packaging, handling, and order processing. International shipping to be determined by destination. Prior to shipment I will need to know the following information (filled out on a form that I will send you) for International Customers or Packages/Freight being Forwarded internationally. International customers may also be subject to a freight forwarder form if applicable.: (1) Are you the end-user of this item? (2) If you are not the ultimate end-user of the item, please state the ultimate end user's name. (3) What is the ultimate country destination? 08/29/12
