| MPN | 130039 |
|---|---|
| Brand | Switch Electronics |
| Manufacturer Part Number | 130039 |
| Contact Configuration | DPDT |
| Current Rating | 10A |
| Mounting Style | Panel |
| Unit uuantity | 1 |
| Current Type | AC/DC |
| Maximum Amperage | 10A |
| Material | PA66 |
| Country of Origin | China |
| Application | Electronics |
| Maximum Operating Voltage | 250VAC |
| Number of Poles | 2 |
| Termination Type | Quick Connect |
| Output Type | Quick Connect |
| EAN | 5063200049915 |
Check the listing for details. Rectangular On-On Rocker Switch DPDT 10A 250V. Condition: New, Made in China. Listed at 15.45 USD. Rectangular On-On Rocker Switch DPDT 10A 250V Rectangular On-On Rocker Switch DPDT 10A 250V £ 3.19 Ask a question Rectangular DPDT rocker switch with quick-connect terminals and a reliable mechanism, suitable for repairing electrical applicances at a low cost. On-On DPDT contacts Rating: 6(4)A 250VAC / 10A 125VAC 4.8 x 0.8mm terminals Panel cut-out: 22 x 19.5mm Dimensions: 24 x 21 x 18.3mm (Width x Length x Height) Technical Information Housing Material Nylon 66 Contact Material Silver Alloy Rating 6(4)A 250VAC / 10A 125VAC Contact Resistance 50mΩ Max Insulation Resistance 100MΩ Min Dielectric Strength 1500V AC 1 Minute Operating Temperature -30°C to +80°C About Us Shop related items eBay & Ecommerce Stores By.
