Check the listing for details. ROSSLARE SECURITY AC-825IP 4 DOOR ACCESS CONTROL PANEL. Condition: New. Listed at 899.99 USD. SPECIAL ORDER: We ship within 4-5 business days via ground from califoria.PRODUCT DESCRIPTIONThe AC-825IP is a state-of-the-art 4-door networked access controller and is the backbone of a medium-scale to high-scale security system. The controller comes with one onboard expansion slot. Using only D-805 door expansion boards, a single AC-825IP can handle up to 58 doors and 60,000 users. Driven by AxTraxNG™ – Rosslare’s powerful, flexible, and easy-to-use software – the system provides an ideal modular and expandable solution for commercial and institutional needs.The AC-825IP access control unit (ACU) supports up to 4 doors (In/Out) via Wiegand protocol, each with 2 inputs and 1 output. Four additional auxiliary inputs and 2 auxiliary outputs are also on board. The AC-825IP includes an encrypted communication via TCP/IP to an AxTraxNG server, and has an additional RS-485 bus for expansion connectivity. In addition, the AC-825IP and its expansions can be placed in a lockable metal enclosure, the ME-1515, which includes a control board, power switcher, built-in power management board/charger, sounder, and a revolutionary enclosure illumination bar that lights up when the enclosure is opened.ACCESS CONTROLLER FEATURESUp to 58 doors, 60,000 users, and 500,000 history log entries (FIFO) per ACUOnboard TCP/IP networking with AES 128-bit data encryption to an AxTraxNG server, bi-directional push communication for enhanced data transmission speed and reliabilitySupports up to 4 doors (In/Out), each with 2 inputs and 1 output4 auxiliary inputs and 2 auxiliary outputs2 RS-485 buses (OSDP and G-Bus)One onboard expansion slot and an additional 12 expansion boards via OSDP (R/S/D/P-805). Call us for expansion board pricing and availabilityR-805 – 16 outputsS-805 – 16 inputsD-805 – 4-door expansionP-805 – 16 inputs and 8 outputsAn additional ME-1515 metal enclosure holds up to 2 expansion boards and includes all the innovative features of the AC-825IP enclosureSD card slot with 8GB card includedReal-time clock keeps time for up to 2 weeks without power (no batteries to replace)Spacious and lockable metal enclosure, features cable twist locks and zip-tie anchors for better cable managementPower management board indicates battery and power statusRevolutionary enclosure with: illumination bar that lights up when enclosure is opened; tamper sensing; and power status LEDSYSTEM SOFTWARE FEATURESAxTraxNG™ Ultralight networked access control management software. Rosslare’s AxTraxNG™ Ultralight is a Server-Client software management system enabling management of modular networked access control panels. The AxTraxNG™ Ultralight management software is user-friendly, intuitive, reliable, and rich in functionality.Password controlled for high level of securityCompatible with Rosslare’s Networked Access ControllersAdvanced Access Group assignmentComplete Access Monitoring capabilityUser-friendly software with intuitive GUI help reduce the complexity of installationManages user data, photo and information fields, access rights, alarms, strike time, and door mode, all from one central locationCar parking managementCard database automation for automatic deletion of unused cardsProduces attendance reports from acquired dataAvailable in multiple languagesSYSTEM REQUIREMENTS FOR THE AXTRAXNG™ SOFTWARESupported OS: Windows 7 SP1, 8.1 or 10, 32 or 64 bit **Note: Windows XP not supported **Recommended System Requirements: Intel Core I5 dual core 2.5 GHz or equivalent RAM 8GB, 5GB free spaceAXTRAXNG™ SOFTWARE LICENSESoftware license is free up to 256 readers(contact Maglocks.com for more information on license for large installations)PRODUCT SPECIFICATIONSACU Power Supply Voltage: 12 VDC from built-in regulated power management modeuleACU Power Supply Max Current: 4-AmpsRelays: 6 Form-C relays on boards, 4-doors and 2-Aux. expandable with the above listed boardsBattery: 12 volt sealed lead acid (SLA) up to 7 AhMaximum Current for Readers: 1.1-AmpsCapacity: 60,000 usersHistory Event Log Size: 500,000 eventsInputs: 12 supervised (4-doors REX input with 4 door monitors and 4 Aux inputs)Readers: Four Weigand reader ports with tamper and LED control. Two additional readers connected via OSDP. Includes an expansion socket compatable with any of the four above listed exansion boards (R/S/D/P-805 boards)Connectivity: Onboard TCP-I/P OSDP/RSDP-bus, USB expansion-bus for R/S/D/P-805 boards. Call us for expansion board pricing and availabilityOSDP: SupportedEncryption: 128-bit encrypted standardCommunication with AxTraxNG™ Server: Bi-directionalTime Zones and Groups: 256 multi-segment time zones, 64 holidays - each holiday can be of multiple days, practically unlimited access groupsSpecial Features: Interlock, first person delay, auto-relock, scheduled output operation, 4 programmable site codes, extended unlock time parking lot management, fully interconnectednessFirware Upgrade: Local/remore, through AxTraxNG PC softwareProduct Warranty: 2-Year Limited Product WarrantyPRODUCT DIMENSIONSEnclosure Dimensions: (H x W x D) 346mm H x 404mm W x 101mm D (13.6 inches H x 15.9 inches W x 4.0 inches D)Weight: 4.6 kg (10.1 lb)CERTIFICATIONSUL 294
