Check the listing for details. Supermicro A2SDV-8C-LN8F Motherboard. Condition: New. Listed at 798.95 USD. 8-Core Denverton Eight 1GbE RJ45 Intel® Quick Assist Technology Key Features Intel® Atom® Processor C3758, Single Socket FCBGA1310 supported, CPU TDP support 25WSystem on ChipUp to 256GB Registered ECC DDR4-2400MHz, Up to 64GB Unbuffered ECC/Non-ECC DDR4-2400MHz; in 4 DIMM slotsExpansion slots: 1 PCI-E 3.0 x4 (Slot 6 or 7 option)M.2 Interfaces: 1 M-Key 2242/80 supports PCI-E 3.0 x2/SATA 1 B-Key 3042/2280 supports PCI-E 3.0 x2/SATA/USB8x 1GbE RJ45 LAN ports5 SATA3 (6 Gbps) portsI/O: 1 VGA, 1 COM (1 via header), TPM header3 USB 3.0 (2 rear, Type-A) 2 USB 2.0 (2 via headers)Intel Quick Assist TechnologySupports 12V DC power input Links & Resources Tested Memory List Tested HDD / SSD List Tested AOC List Motherboard Manual Quick Reference Guide Update Your BIOS BMC/IPMI Firmware Download the Latest Drivers and Utilities Download Driver CDOS CompatibilityTested M.2 List Product SKUs MBD-A2SDV-8C-LN8F A2SDV-8C-LN8F Physical Stats Form Factor Flex ATX 9.0" x 7.25" Dimensions 9" x 7.25" (22.86cm x 18.42cm) Processor/Cache CPU Intel® Atom® Processor C3758.Single Socket FCBGA1310 supported, CPU TDP support 25W Cores / Cache 8 cores, 8 threads / 16MB cache System Memory Memory Capacity Up to 256GB Registered ECC RDIMM, DDR4-2400MHzUp to 64GB Unbuffered ECC/non-ECC UDIMM, DDR4-2400MHz, in 4 DIMM slots Memory Type 2400/2133/1866/1600MHz DIMM Sizes 4GB, 8GB, 16GB, 32GB, 64GB Memory Voltage 1.2V Error Detection Corrects single-bit errors Detects double-bit errors (using ECC memory) On-Board Devices Chipset System on Chip SATA SoC controller for 5 SATA3 (6 Gbps) ports; IPMI ASPEED AST2400 BMC Network Controllers Quad LAN with Intel® C3000 SoC Quad LAN with Intel® Ethernet Controller I350-AM4 Graphics Aspeed AST2400 BMC Input / Output LAN 8 RJ45 Gigabit Ethernet LAN ports1 RJ45 Dedicated IPMI LAN port USB 2 USB 2.0 ports (2 headers),3 USB 3.0 ports (2 rear + 1 Type A) Video Output 1 VGA port Serial Port / Header 1 COM Port (1 header) TPM TPM Header Expansion Slots PCI-E 1 PCI-E 3.0 x4Option for Slot 6 or Slot 7 M.2 1 M.2 M-Key SATA/PCI-E 3.0 x2, 2242/22801 M.2 B-Key SATA/PCI-E 3.0 x2/USB 3.0, 3042/2280 System BIOS BIOS Type AMI UEFI BIOS Features UEFI 2.4SMBIOS 2.7.1 Management Software IPMI2.0, NMI, SuperDoctor® 5, Watchdog Power Configurations ATX Power connector+12V DC Power InputCPU thermal trip support for processor protectionPower-on mode for AC power recovery PC Health Monitoring Voltage +12V, +3.3V, +5V, +5V standby, 1.05 (PCH), 1.2V (VDIMM), 3.3V standby, 5 -fan status, Chassis intrusion header, VBAT FAN 5x 4-pin fan headers (up to 5 fans), 5 fans with tachometer status monitoring, Dual Cooling Zone, Fan speed control Temperature CPU thermal trip support LED UID/Remote UID Other Features 4-pin 12v DC power connector, ACPI power management, ATX Power connector, Chassis intrusion header, Dual Cooling Zones, Intel® QuickAssist Technology , M.2 NGFF connector, RoHS, UID Operating Environment Operating Temperature Range 0°C ~ 60°C (32°F ~ 140°F) Non-Operating Temperature Range -40°C - 85°C (-40°F - 185°F) Operating Relative Humidity Range 10% ~ 85% (non-condensing) Non-Operating Relative Humidity Range 10% ~ 95% (non-condensing) Parts List (Bulk Package) Name Part Number Qty Description Motherboard MBD-A2SDV-8C-LN8F 1 A2SDV-8C-LN8F Motherboard SATA Cables CBL-0044L257.5CM SATA FLAT S-S PBF I/O Shield MCP-260-00133-0N1Standard I/O Shield for A2SDV-LN8F/LN10PF Parts List (Retail Package) Name Part Number Qty Description Motherboard MBD-A2SDV-8C-LN8F 1 A2SDV-8C-LN8F Motherboard QRGMNL-2113-QRG1Motherboard Quick Reference GuideSATA Cables CBL-0044L557.5CM SATA FLAT S-S PBF I/O Shield MCP-260-00133-0N1Standard I/O Shield for A2SDV-LN8F/LN10PFPlastic StandoffFST-SCRW-00101Stand Off, H=3MM
