Check the listing for details. Battery Internal Resistance Meter AC Low Ohm Meter Voltage Accuracy 0.01%. Condition: New. Listed at 1629.84 USD. Battery Internal Resistance Meter AC Low Ohm Meter Voltage Accuracy 0.01% It adopts high-performance 32-bit ARM microprocessor-controlled miniature benchtop instrument for automatic real-time detection. The instrument uses a 4.3-inch true-color LCD display, which is operated in a full-touch mode, providing a brand-new instrument interaction experience. The instrument can test 0.0001mΩ~3.3kΩ resistance, 0.00001~200.000V DC voltage, resistance 33000 display digits, voltage 200000 display digits. AT527A has the characteristics of high precision, high resolution and ultra-high speed measurement at the same time, providing 0.5% resistance accuracy and 0.01% voltage accuracy, and the measurement speed can reach 55 times/second. The instrument is used for professional sorting function. It is equipped with a Handler (PLC) interface as standard, and independently outputs resistance HIGH/IN/LOW signal and voltage HIGH/IN/LOW signal, which can fully cope with high-speed automatic sorting system to complete automatic assembly line test. At the same time, the enhanced IO signal can directly drive the power relay and signal relay. The instrument has built-in RS-232C interface and USB-232 interface. The instrument comes standard with general data acquisition software, with its own database function and Excel export function, which can be effectively used for remote control and data acquisition and analysis. The instrument uses Anbai Instruments' to enhanced the computer remote control command set, which is compatible with SCPI (programmable instrument standard command set) and Modbus protocol (Modbus has become a national standard GB/T19582-2008) are applied to the automatic sorting system to complete the automatic assembly line test. , and efficiently complete the remote control and data acquisition functions. Feature:33000 AC resistance readings, 600.000 DC voltage readingResistance test range: 0.0001mΩ~3.3000kΩVoltage test range: 0.00001V~200.000VDC0.5% resistance accuracy0.01% voltage accuracyHANDLER interfaceRS-232C and USB communication interfaceU disk real-time storage full touch operation Specification:ParametersACR, DCVAccuracyResistance accuracy: 0.5%，Voltage accuracy: 0.01%RangeTest range：0.0001mΩ~3kΩ & 0.00001~200.000VSignal Source1kHz, stable frequency: 20ppmRange3mΩ~3kΩ with 7 range test.Auto, manual, Nominal.SpeedAll channels open with manual operation: slow 3 times/s, medium:20times/s, fast 40times/s, high-speed 70times/secondResult Displayshow, ,ΔABS,Δ%,θ,sorting resultDisplay MaxR: 33,000 V：400,000Adjustmentshort-circuit reset full rangeComparatorsorting function.RHI/RNG/RLO output. VHI/VNG/VLO output. NG/OK output. compare way: Absolute value tolerance ±TOL sorting: the absolute deviation between the measured value and the nominal value is compared with the limits of each file. Percent tolerance %TOL sorting: the percentage deviation between the measured value and the nominal value is compared with the limits of each file. Sequential comparison sorting: the measured value is directly compared with the upper and lower limitsTriggerInternal, Manual, External , RemoteInterfaceHANDLER, RS-232C, USBOptionsATL527APowerV:195VAC～245VAC Fre：50Hz Power：15VADimensions264 x107x350 mmMass4KGAccessoriesATL527 kelvin test cable,ATL108 RS232 communication cableOther functions4.3 inch TFT-LCD color display, full touch operation Applications:Various contact resistance testsDetermination of deterioration and life evaluation of alkaline batteries, lead storage batteries, and lithium batteriesBattery factory inspectionSuper Capacitor Equivalent Resistance (ESR) Measurement
